ABB AC800M 系列中的 PM891AK02 冗余控制器單元 是專為工業自動化設計的核心控制設備,屬于瑞典 ABB 公司推出的 分布式控制系統(DCS) 解決方案的一部分。
核心特性
冗余設計
采用雙機熱備(Redundant Configuration),主備控制器實時同步數據,確保單點故障時系統無擾動切換(切換時間通常 < 50ms),滿足高可用性需求。
支持冗余電源、冗余通信模塊,全面提升系統可靠性。
高性能計算能力
基于高性能處理器,支持復雜控制算法(如先進控制、批量控制、邏輯運算等)。
適用于大規模 I/O 點數及高速數據采集場景。
模塊化擴展
支持通過背板總線擴展 I/O 模塊、通信模塊(如以太網、Profibus、Modbus 等),靈活適配不同工藝需求。
集成性與兼容性
深度集成 ABB 的 System 800xA 控制平臺,支持統一工程環境(如控制策略組態、HMI 設計)。
兼容 IEC 61131-3 標準,支持多種編程語言(梯形圖、功能塊圖、結構化文本等)。
行業認證
通過 SIL 2/3 安全認證,適用于關鍵工藝段的冗余控制。
符合嚴苛的工業環境標準(如溫度、電磁干擾防護)。
典型應用場景
電力行業:燃?xì)廨啓C(jī)、蒸汽輪機控制,電網穩定控制。
石油化工:連續生產過程控制,安全聯鎖系統(SIS)。
水處理與環保:污水處理廠、廢氣排放監控系統。
制藥與食品飲料:批次生產過程控制,符合 FDA 21 CFR Part 11 規范。
技術規格(示例)
處理器:多核 CPU,支持多任務實時操作系統。
內存:大容量 RAM + Flash 存儲,支持控制程序與數據長期保存。
通信接口:冗余以太網、Profibus DP、Modbus TCP/IP 等。
I/O 容量:可擴展至數千點,支持模擬量、數字量、脈沖量輸入/輸出。
工作環境:溫度范圍 -20°C 至 60°C,抗振動/沖擊設計。
冗余機制
同步機制:主備控制器通過高速總線(如光纖)實時同步數據,確保狀態一致。
故障檢測:硬件自檢、看門狗定時器、通信鏈路監控。
無擾切換:故障時備用控制器立即接管,控制輸出保持連續,避免工藝波動。



The PM891AK02 redundant controller unit in the ABB AC800M series is a core control equipment designed specifically for industrial automation, and is part of the distributed control system (DCS) solution launched by ABB in Sweden.
core features
Redundant design
Adopting a dual machine hot standby configuration, the primary and backup controllers synchronize data in real-time to ensure uninterrupted system switching in the event of a single point of failure (switching time is usually less than 50ms), meeting high availability requirements.
Supporting redundant power supplies and communication modules to comprehensively enhance system reliability.
High performance computing capability
Based on high-performance processors, it supports complex control algorithms such as advanced control, batch control, logical operations, etc.
Suitable for large-scale I/O points and high-speed data acquisition scenarios.
Modular expansion
Support the expansion of I/O modules and communication modules (such as Ethernet, Profibus, Modbus, etc.) through backplane bus, flexibly adapting to different process requirements.
Integration and compatibility
Deeply integrated with ABB's System 800xA control platform, supporting unified engineering environments such as control strategy configuration and HMI design.
Compatible with IEC 61131-3 standard, supporting multiple programming languages such as ladder diagrams, functional block diagrams, structured text, etc.
Industry certification
Through SIL 2/3 safety certification, it is suitable for redundant control in critical process sections.
Compliant with stringent industrial environmental standards such as temperature and electromagnetic interference protection.
Typical application scenarios
Power industry: gas turbine, steam turbine control, grid stability control.
Petrochemical industry: continuous production process control, safety interlock system (SIS).
Water treatment and environmental protection: sewage treatment plants, exhaust gas emission monitoring systems.
Pharmaceutical and Food Beverage: Batch production process control, in compliance with FDA 21 CFR Part 11 specifications.
Technical specifications (example)
Processor: Multi core CPU, supporting multitasking real-time operating systems.
Memory: Large capacity RAM+Flash storage, supporting long-term storage of control programs and data.
Communication interfaces: redundant Ethernet, Profibus DP, Modbus TCP/IP, etc.
I/O capacity: expandable to thousands of points, supporting analog, digital, and pulse input/output.
Working environment: Temperature range -20 ° C to 60 ° C, anti vibration/impact design.
Redundancy Mechanism
Synchronization mechanism: The primary and backup controllers synchronize data in real-time through high-speed buses (such as optical fibers) to ensure consistent status.
Fault detection: hardware self-test, watchdog timer, communication link monitoring.
Disturbance free switching: In case of a fault, the backup controller immediately takes over, and the control output remains continuous to avoid process fluctuations.
