WOODWARD 2301E 8273-1011 控制模塊
產品概述
WOODWARD 2301E 8273-1011 是一款基于微處理器的數字控制模塊，專為工業自動化和發動機控制系統設計。它能夠?qū)崿F(xiàn)對柴油或氣體發動機驅動的發電機的負載分配和速度控制。
技術規格
輸入電壓：24V DC（工作范圍 18-36V DC）。
輸出電壓：4-20 mA DC 或 0-10 V DC。
工作溫度范圍：-40°C 至 +85°C。
尺寸：96 x 48 x 100 mm 或 150 mm × 100 mm × 50 mm。
重量：約 0.15 kg 或 100g。
安裝方式：DIN 導軌安裝。
通信接口：RS-232、RS-422 和 RS-485。
控制功能：
1 個負載傳感器電路。
1 個執行器驅動器（支持 4-20 mA、0-20 mA、0-200 mA 或 PWM 輸出）。
1 個 MPU 速度傳感器。
1 個可配置模擬輸出。
2 個可配置模擬輸入。
8 個離散（開關）輸入（3 個可配置）。
4 個離散（繼電器驅動器）輸出（1 個固定，3 個可配置）。
功能特點
高精度控制：提供精確的速度和負載控制，速度控制精度可達 ±0.25%。
靈活性：可通過程序進行配置和調整，適應不同的應用場景。
可靠性：設計緊湊且耐用，適用于多種工業環境。
多功能性：兼容廣泛的工業設備和系統。
故障檢測與保護：具備故障檢測功能，可監測系統和傳感器的狀態，并在出現問題時觸發警報。
數據記錄與通信：支持多種通信協議（如 Modbus、Ethernet 等），便于與其他系統和設備集成。
應用領域
發電機組控制：用于柴油或氣體發動機驅動的發電機的負載分配和速度控制。
燃?xì)廨啓C(jī)控制：在燃?xì)廨啓C(jī)控制系統中，實現精確的轉速和負載控制。
水輪機控制：用于混流式水輪機等設備的轉速和負載控制。
工業自動化：在工業自動化領域，作為核心控制模塊，實現設備的自動化運行。
其他應用：適用于需要調速控制的電機驅動應用，如風機、泵、壓縮機等。
Woodward 2301e 8273-1011 control module
Product overview
Woodward 2301e 8273-1011 is a microprocessor-based digital control module designed for industrial automation and engine control systems. It can realize the load distribution and speed control of diesel or gas engine driven generators.
technical specifications
Input voltage: 24V DC (working range: 18-36V DC).
Output voltage: 4-20 mA DC or 0-10 V DC.
Operating temperature range: -40 ° C to+85 ° C.
Dimensions: 96 X 48 x 100 mm or 150 mm x 100 mm x 50 mm.
Weight: about 0.15 kg or 100g.
Installation method: DIN rail installation.
Communication interface: RS-232, RS-422 and RS-485.
Control function:
1 load sensor circuit.
1 actuator driver (supports 4-20 mA, 0-20 Ma, 0-200 Ma or PWM output).
1 MPU speed sensor.
1 configurable analog output.
2 configurable analog inputs.
8 discrete (switch) inputs (3 configurable).
4 discrete (relay driver) outputs (1 fixed, 3 configurable).
Functional features
High precision control: provide accurate speed and load control, and the speed control accuracy can reach ± 0.25%.
Flexibility: it can be configured and adjusted through the program to adapt to different application scenarios.
Reliability: compact and durable design, suitable for a variety of industrial environments.
Versatility: compatible with a wide range of industrial equipment and systems.
Fault detection and protection: with fault detection function, it can monitor the status of the system and sensors, and trigger an alarm in case of problems.
Data recording and communication: support a variety of communication protocols (such as modbus, Ethernet, etc.) to facilitate integration with other systems and equipment.
application area
Generator set control: used for load distribution and speed control of diesel or gas engine driven generators.
Gas turbine control: in the gas turbine control system, accurate speed and load control is realized.
Turbine control: used for speed and load control of Francis turbine and other equipment.
Industrial automation: in the field of industrial automation, as the core control module, it realizes the automatic operation of equipment.
Other applications: suitable for motor drive applications requiring speed control, such as fans, pumps, compressors, etc.
If you need to further understand or purchase Woodward 2301e 8273-1011 control module, it is recommended to contact the relevant supplier
