TRICONEX 3704E 數字量輸入模塊 SIS安全系卡件

TRICONEX 3704E 數字量輸入模塊 SIS 安全系卡件是一款專為工業安全系統設計的高性能模塊，廣泛應用于石油、化工、電力等關鍵行業，具備高可靠性、冗余設計和靈活配置能力，是安全儀表系統（SIS）的核心組件之一。 一、產品概述 品牌與型號：TRICONEX 3704E 類型：數字量輸入模塊（部分資料提及為模擬量輸入模塊，但主流定位為數字量輸入） 用途：采集現場數字信號（如開關狀態、傳感器信號等），用于安全聯鎖和緊急停車系統（ESD）。 兼容性：與 Triconex Trident 安全儀表系統完全兼容，支持 TriStation 1131 軟件進行配置和監控。 二、技術規格 輸入通道： 數量：64 個數字量輸入通道（部分資料提及 32 個，可能為不同版本或配置）。 信號類型：支持干觸點（無源）或濕觸點（有源）輸入，兼容 24VDC 電壓。 響應時間：典型值小于 75 毫秒（部分資料提及 10 毫秒，可能因版本或配置不同）。 性能參數： 輸入電壓范圍：24VDC（18-30VDC 可接受范圍）。 輸入電流：典型值 5mA（干觸點）或 10mA（濕觸點）。 隔離等級：通道間隔離電壓達 2000VDC，確保信號獨立性和抗干擾能力。 環境適應性： 工作溫度：-40°C 至 +70°C（工業級寬溫設計）。 濕度范圍：5% 至 95% RH（非凝結）。 防護等級：IP20（機架安裝型）。 冗余設計： 三重模件冗余（TMR）：模塊內置三個獨立子電路，執行相同邏輯并通過表決機制輸出結果，單個故障不影響系統運行。 自診斷功能：實時監測硬件狀態，故障時自動切換至備用通道。 三、功能特性 高可靠性： TMR 架構確保系統在單點故障時仍能正常運行，滿足 SIL 3 安全等級要求。 輸入通道具備防抖動和去干擾功能，避免誤觸發。 靈活配置： 每個通道可單獨配置輸入類型（干/濕觸點）、濾波時間和報警閾值。 支持熱插拔，可在不中斷系統運行的情況下更換模塊。 診斷與維護： 內置診斷 LED 指示燈，顯示模塊狀態（通過、故障、激活）。 提供詳細的故障日志，便于快速定位和修復問題。 兼容性與擴展性： 支持與 Triconex Trident 系統無縫集成，可擴展至最多 118 個 I/O 模塊。 支持 Modbus、TCP/IP 等通信協議，便于與其他設備或系統進行數據交互。 四、應用領域 石油與天然氣：油氣管道壓力監測、井口設備控制。 化工：反應釜溫度/壓力聯鎖、緊急停車系統（ESD）。 電力：發電機組狀態監測、電網安全控制。 制造業：自動化生產線安全聯鎖、設備故障保護。 五、優勢總結 高安全性：TMR 架構和冗余設計滿足 SIL 3 安全等級，確保關鍵工藝過程的安全可靠。 高靈活性：可配置的通道參數和熱插拔功能，適應不同工業場景需求。 易用性：支持 TriStation 1131 軟件進行配置和監控，降低使用門檻。 廣泛兼容性：與 Triconex Trident 系統及其他主流 DCS（分布式控制系統）兼容。 六、注意事項 在安裝前，請確保模塊與系統固件版本兼容，避免因版本不匹配導致功能異常。 模塊應安裝在符合環境要求的機柜中，避免高溫、高濕或強電磁干擾環境。 如需進行定制或擴展功能，請聯系 Triconex 的技術支持團隊。

The TRICONEX 3704E digital input module SIS safety system card is a high-performance module designed specifically for industrial safety systems, widely used in key industries such as petroleum, chemical, and power. It has high reliability, redundant design, and flexible configuration capabilities, and is one of the core components of Safety Instrumented Systems (SIS).

1、 Product Overview

Brand and Model: TRICONEX 3704E

Type: Digital Input Module (Some materials mention analog input modules, but the mainstream positioning is digital input)

Purpose: To collect on-site digital signals (such as switch status, sensor signals, etc.) for safety interlocking and emergency shutdown systems (ESD).

Compatibility: Fully compatible with the Triconex Trident safety instrumented system, supporting TriStation 1131 software for configuration and monitoring.

2、 Technical specifications

Input channel:

Quantity: 64 digital input channels (some sources mention 32, which may be different versions or configurations).

Signal type: Supports dry contact (passive) or wet contact (active) input, compatible with 24VDC voltage.

Response time: Typically less than 75 milliseconds (some sources mention 10 milliseconds, which may vary depending on version or configuration).

Performance parameters:

Input voltage range: 24VDC (acceptable range 18-30VDC).

Input current: Typical value of 5mA (dry contact) or 10mA (wet contact).

Isolation level: The isolation voltage between channels reaches 2000VDC, ensuring signal independence and anti-interference ability.

Environmental adaptability:

Working temperature:- 40 ° C to+70 ° C (industrial grade wide temperature design).

Humidity range: 5% to 95% RH (non condensing).

Protection level: IP20 (rack mounted type).

Redundant design:

Triple Modular Redundancy (TMR): The module contains three independent sub circuits that execute the same logic and output results through a voting mechanism. A single fault does not affect system operation.

Self diagnostic function: Real time monitoring of hardware status, automatically switching to backup channel in case of failure.

3、 Functional characteristics

High reliability:

The TMR architecture ensures that the system can still operate normally in the event of a single point of failure, meeting SIL 3 safety level requirements.

The input channel has anti shake and anti-interference functions to avoid false triggering.

Flexible configuration:

Each channel can be individually configured with input type (dry/wet contacts), filtering time, and alarm threshold.

Supports hot swapping, allowing for module replacement without interrupting system operation.

Diagnosis and maintenance:

Built in diagnostic LED indicator light, displaying module status (pass, fault, activated).

Provide detailed fault logs for quick identification and repair of issues.

Compatibility and Scalability:

Support seamless integration with the Triconex Trident system, expandable to up to 118 I/O modules.

Supports communication protocols such as Modbus and TCP/IP, facilitating data exchange with other devices or systems.

4、 Application Fields

Oil and gas: pressure monitoring of oil and gas pipelines, control of wellhead equipment.

Chemical industry: reactor temperature/pressure interlock, emergency shutdown system (ESD).

Electricity: monitoring the status of generator sets and controlling the safety of the power grid.

Manufacturing industry: Automated production line safety interlocking, equipment fault protection.

5、 Summary of Advantages

High safety: TMR architecture and redundant design meet SIL 3 safety level, ensuring the safety and reliability of critical process flows.

High flexibility: configurable channel parameters and hot swappable functionality to meet the needs of different industrial scenarios.

Usability: Supports TriStation 1131 software for configuration and monitoring, reducing the threshold for use.

Wide compatibility: Compatible with Triconex Trident systems and other mainstream DCS (distributed control systems).

6、 Precautions

Before installation, please ensure that the module is compatible with the system firmware version to avoid functional abnormalities caused by version mismatch.

The module should be installed in a cabinet that meets environmental requirements, avoiding high temperature, high humidity, or strong electromagnetic interference environments.

If customization or expansion of functionality is required, please contact Triconex's technical support team.
