VIBRO-METER VM600 CPUM 200-595-067-114輸入/輸出模塊/卡件是VIBRO-METER VM600振動監測系統的重要組成部分。
一、基本概述
品牌：VIBRO-METER
型號：VM600 CPUM 200-595-067-114
類型：輸入/輸出模塊/卡件
二、結構與設計
CPUM/IOCN卡對：該模塊通常與VM600系統機架（ABE04x）一起使用。CPUM卡既可單獨使用，也可與相關IOCN卡一起作為卡對使用，具體取決于應用/系統要求。
插槽占用：CPUM是雙寬卡，占用兩個VM600機架插槽（卡位）；IOCN是單寬卡，占用一個VM600插槽。
安裝位置：CPUM安裝在機架前部（插槽0和1），相關的IOCN安裝在機架后部CPUM正后方的插槽（插槽0）。
連接方式：每張卡通過兩個連接器直接連接到機架背板。
三、功能特點
模塊化、高通用性設計：所有VM600機架配置、顯示和通信接口均可通過“聯網”機架中的一張卡來完成。
機架控制器：CPUM卡作為“機架控制器”，可在機架和運行VM600 MPSx軟件包（MPS1或MPS2）的計算機之間建立以太網鏈接。
高度集成：具有緊湊的設計，可以方便地集成到現有的系統中。
高可靠性：這些模塊經過嚴格的質量控制和測試，以確保其在各種環境條件下都能穩定運行。
易于使用：具有簡單的接口和易于使用的特性，可以方便地與各種設備進行連接和配置。
靈活的配置：可以根據特定的應用需求進行靈活的配置，以滿足不同的控制和監測要求。
四、技術規格
通道數：16個動態通道和4個轉速通道。
處理輸出：每個動態通道和每個雙通道最多20個處理輸出（每個xmc 16 12個）。
采樣方式：利用異步（固定頻率）或同步（順序跟蹤）采樣在所有通道上同時采集數據。
數據采集與處理：24位數據采集，高信噪比數據處理，高分辨率FFT高達每500ms 6400行。
五、應用與場景
VIBRO-METER VM600 CPUM 200-595-067-114輸入/輸出模塊/卡件主要用于振動監測系統中，用于采集振動信號、進行數據處理和提供用戶接口。它適用于各種機械設備的振動監測和分析，以及工業自動化和控制應用中的振動保護。
The input/output module/card of VIBRO-METER VM600 CPUM 200-595-067-114 is an important component of the VIBRO-METER VM600 vibration monitoring system.
1、 Basic Overview
Brand: VIBRO-METER
model: VM600 CPUM 200-595-067-114
Type: Input/Output Module/Card
2、 Structure and Design
CPUM/IOCN card pair: This module is typically used with VM600 system racks (ABE04x). The CPUM card can be used alone or as a card pair with related IOCN cards, depending on the application/system requirements.
Slot occupancy: CPUM is a dual wide card that occupies two VM600 rack slots (card slots); IOCN is a single wide card that occupies one VM600 slot.
Installation position: The CPUM is installed at the front of the rack (slots 0 and 1), and the related IOCN is installed at the slot directly behind the CPUM at the back of the rack (slot 0).
Connection method: Each card is directly connected to the rack backplane through two connectors.
3、 Functional Features
Modular and high usability design: All VM600 rack configurations, displays, and communication interfaces can be completed through a single card in the "networked" rack.
Rack Controller: The CPUM card serves as the "rack controller" and can establish an Ethernet link between the rack and the computer running the VM600 MPSx software package (MPS1 or MPS2).
Highly integrated: With a compact design, it can be easily integrated into existing systems.
High reliability: These modules undergo strict quality control and testing to ensure stable operation under various environmental conditions.
Easy to use: With a simple interface and user-friendly features, it can be easily connected and configured with various devices.
Flexible configuration: It can be flexibly configured according to specific application requirements to meet different control and monitoring requirements.
4、 Technical specifications
Number of channels: 16 dynamic channels and 4 speed channels.
Processing outputs: Each dynamic channel and each dual channel can have up to 20 processing outputs (16 12 per XMC).
Sampling method: Using asynchronous (fixed frequency) or synchronous (sequential tracking) sampling to simultaneously collect data on all channels.
Data acquisition and processing: 24 bit data acquisition, high signal-to-noise ratio data processing, high-resolution FFT up to 6400 lines per 500ms.
5、 Applications and Scenarios
The VIBRO-METER VM600 CPUM 200-595-067-114 input/output module/card is mainly used in vibration monitoring systems for collecting vibration signals, processing data, and providing user interfaces. It is suitable for vibration monitoring and analysis of various mechanical equipment, as well as vibration protection in industrial automation and control applications.
