PROSOFT PLX32-EIP-PND 可編程控制器是一款工業通信網關設備，專為實現 EtherNet/IP 和 PROFINET 兩種工業以太網協議之間的無縫通信而設計。它廣泛應用于工業自動化領域，特別是在需要跨協議數據交換的場景中，幫助用戶實現不同網絡和設備之間的互聯互通。
產品特點 協議轉換功能 支持 EtherNet/IP 和 PROFINET 協議之間的雙向數據傳輸。 允許 EtherNet/IP 控制器與 PROFINET 控制器或設備進行實時通信。 雙網口設計 提供兩個獨立的以太網端口，分別用于連接 EtherNet/IP 網絡和 PROFINET 網絡。 支持不同子網配置，增強網絡靈活性。
工業級設計 采用堅固的金屬外殼，適應惡劣的工業環境。 支持寬溫工作范圍，具備高抗振動和抗沖擊能力。 易于集成 提供詳細的配置工具和用戶手冊，簡化設備配置過程。 支持與主流 PLC 和 HMI 系統集成，方便用戶快速部署。 高可靠性 內置冗余和故障恢復機制，確保通信的穩定性和可靠性。 經過嚴格測試，符合工業通信標準。 技術參數 網絡接口：2 個 10/100Mbps 以太網端口（RJ45）。 協議支持：EtherNet/IP 主站/從站，PROFINET IO 控制器/設備。 電源電壓：24VDC（18-30VDC 范圍）。 工作溫度：-20°C 至 70°C。 防護等級：IP20（標準），可選 IP67 防護版本。
應用場景
制造業
實現不同品牌 PLC（如西門子、羅克韋爾）之間的數據交換。
連接工業機器人、傳感器和執行器，實現統一控制。
過程控制
在化工、石油和天然氣行業中，連接分布式控制系統（DCS）和現場設備。
實現遠程監控和數據采集。
樓宇自動化
集成樓宇管理系統（BMS）和照明、空調等子系統。
提高樓宇能源效率和設備管理效率。
物流和倉儲
連接自動化倉庫管理系統（WMS）和輸送帶、分揀機等設備。
實現實時庫存管理和訂單處理。
配置與使用
硬件連接
將 EtherNet/IP 網絡連接到網關的一個以太網端口。
將 PROFINET 網絡連接到另一個以太網端口。
為網關提供 24VDC 電源。
軟件配置
使用 ProSoft 提供的配置工具（如 ProSoft Configuration Builder）進行參數設置。
配置 EtherNet/IP 和 PROFINET 網絡的 IP 地址、子網掩碼和設備名稱。
定義數據映射關系，指定需要交換的數據點。
調試與測試
通過網關的 LED 指示燈或配置工具檢查網絡連接狀態。
使用網絡分析工具驗證數據傳輸?shù)恼_性和實時性。
優勢
簡化系統集成：用戶無需更換現有設備，即可實現不同協議之間的通信。
降低維護成本：統一的通信平臺減少了系統復雜性和維護工作量。
提高生產效率：實時數據交換支持更快的決策和響應時間。
注意事項
確保 EtherNet/IP 和 PROFINET 網絡的 IP 地址不沖突。
根據實際應用需求選擇合適的網關型號（如是否需要冗余功能）。
在配置數據映射時，注意數據類型和長度的匹配。
PROSOFT PLX32-EIP-PND programmable controller is an industrial communication gateway device designed to achieve seamless communication between EtherNet/IP and PROFINET industrial Ethernet protocols. It is widely used in the field of industrial automation, especially in scenarios that require cross protocol data exchange, to help users achieve interconnectivity between different networks and devices.
Product Features
Protocol conversion function
Supports bidirectional data transmission between EtherNet/IP and PROFINET protocols.
Allow real-time communication between EtherNet/IP controllers and PROFINET controllers or devices.
Dual network port design
Provide two independent Ethernet ports, one for connecting to EtherNet/IP network and the other to PROFINET network.
Support different subnet configurations to enhance network flexibility.
Industrial grade design
Adopting a sturdy metal casing to adapt to harsh industrial environments.
Supports a wide temperature range and has high resistance to vibration and impact.
Easy to integrate
Provide detailed configuration tools and user manuals to simplify the device configuration process.
Support integration with mainstream PLC and HMI systems, facilitating quick deployment for users.
high reliability
Built in redundancy and fault recovery mechanisms ensure the stability and reliability of communication.
After rigorous testing, it meets industrial communication standards.
Technical Parameter
Network interface: 2 10/100Mbps Ethernet ports (RJ45).
Protocol support: EtherNet/IP master/slave, PROFINET IO controller/device.
Power supply voltage: 24VDC (18-30VDC range).
Working temperature:- 20 ° C to 70 ° C.
Protection level: IP20 (standard), optional IP67 protection version.
Application scenarios
manufacturing
Realize data exchange between different brands of PLCs (such as Siemens, Rockwell).
Connect industrial robots, sensors, and actuators to achieve unified control.
process control
In the chemical, petroleum, and natural gas industries, connecting distributed control systems (DCS) and on-site equipment.
Implement remote monitoring and data collection.
Building Automation
Integrate building management system (BMS) and subsystems such as lighting and air conditioning.
Improve building energy efficiency and equipment management efficiency.
Logistics and warehousing
Connect automated warehouse management systems (WMS) with conveyor belts, sorting machines, and other equipment.
Implement real-time inventory management and order processing.
Configuration and usage
Hardware connection
Connect the EtherNet/IP network to one Ethernet port of the gateway.
Connect the PROFINET network to another Ethernet port.
Provide 24VDC power supply for the gateway.
software configuration
Use the configuration tool provided by ProSoft (such as ProSoft Configuration Builder) to set parameters.
Configure the IP address, subnet mask, and device name for EtherNet/IP and PROFINET networks.
Define data mapping relationships and specify the data points that need to be exchanged.
Debugging and Testing
Check the network connection status through the LED indicator lights or configuration tools of the gateway.
Use network analysis tools to verify the correctness and real-time performance of data transmission.
advantage
Simplified system integration: Users can achieve communication between different protocols without replacing existing devices.
Reduce maintenance costs: A unified communication platform reduces system complexity and maintenance workload.
Improve production efficiency: Real time data exchange supports faster decision-making and response times.
precautions
Ensure that the IP addresses of EtherNet/IP and PROFINET networks do not conflict.
ｓｅｌｅｃｔ the appropriate gateway model based on actual application requirements (such as whether redundant functionality is required).
When configuring data mapping, pay attention to matching data types and lengths.
