NI USB-4432 是一款專為聲音和振動應用設計的高性能數據采集卡。以下是其主要特點和功能：
最大采樣率：102.4 kS/s，能夠提供高精度的信號采集 。
模擬輸入通道：最大差分模擬輸入通道數量為5，其中4個通道集成了用于加速度計和麥克風的集成電子壓電(IEPE)信號調理功能，第五個輸入通道不提供IEPE支持 。
模擬輸入耦合：支持AC-DC耦合，適用于各種信號類型 。
高通濾波器截止頻率：0.1 Hz，內置抗混疊濾波器，可自動調整至采樣率 。
輸入接口：正面連接式為BNC，提供5個BNC接口 。
總線連接器：采用USB 2.0接口，方便與計算機連接 。
動態范圍：100 dB，確保在各種應用中都能提供高質量的信號采集 。
電源要求：工作電壓為5V±0.25V，適用于多種電源環境 。
工作溫度：0℃～70℃，存儲溫度為-10℃～85℃，濕度為5%～95%，適用于各種環境條件 。
軟件支持：提供WIN7/VISTA/2000/XP下的驅動程序及動態連接庫，支持預觸發，最大可預采2K個點 。
此外，NI USB-4432 的技術參數在2011年5月進行了更新，最新的NI-DAQmx驅動解決了在使用這些設備時的主要問題，確保了更高的測試精度和穩定性 。
The NI USB-4432 is a high-performance data acquisition card designed for sound and vibration applications. The following are its main features and functions:
Maximum sampling rate: 102.4kS /s, which can provide high-precision signal acquisition.
Analog input channels: The maximum number of differential analog input channels is 5, four of which integrate integrated Electronic Piezoelectricity (IEPE) signal conditioning for accelerometers and microphones, and the fifth input channel does not provide IEPE support.
Analog input coupling: Support AC-DC coupling, suitable for various signal types.
High-pass filter cut-off frequency: 0.1Hz, built-in anti-aliasing filter, can be automatically adjusted to the sampling rate.
Input interface: Front connection type is BNC, providing 5 BNC interfaces.
Bus connector: USB 2.0 interface, easy to connect with the computer.
Dynamic range: 100 dB, ensuring high quality signal acquisition in a variety of applications.
Power requirements: Operating voltage is 5V±0.25V, suitable for a variety of power supply environments.
Operating temperature: 0 ° C ~ 70 ° C, storage temperature: -10 ° C ~ 85 ° C, humidity: 5% ~ 95%, suitable for various environmental conditions.
Software support: Provide WIN7/VISTA/2000/XP under the driver and dynamic connection library, support pre-trigger, maximum pre-pick 2K points.
In addition, the technical parameters of the NI USB-4432 were updated in May 2011, and the latest NI-DAQMX drivers solve the main problems when using these devices, ensuring higher test accuracy and stability.
