PXIe-4143 4通道精密PXI源測量單元

PXIe-4143 4通道精密PXI源測量單元

PXIe-4143 4通道精密PXI源測量單元

PXIe-4143 4通道精密PXI源測量單元（SMU）是一款高性能的測試儀器，專為高引腳數應用設計。以下是對該產品的詳細介紹：

一、產品概述

• 品牌：美國國家儀器（National Instruments，簡稱NI）
• 型號：PXIe-4143
• 類型：4通道精密PXI源測量單元

二、技術規格

1. 通道數：4個相同的SMU通道，適合并行測試。
2. 電壓范圍：±24V，滿足多種測試需求。
3. 電流范圍：±150mA，適用于低功率應用。
4. 電流靈敏度：高電流測量靈敏度，非常適合測量包括無功電流在內的各種電流特征。
5. 運行模式：采用四象限運行模式，每個通道集成了遠程（4線）傳感功能，確保測量準確性。

三、產品特點

1. 高精度：集成式感測功能和高電流測量靈敏度，提供高精度的測量結果。
2. 高速性：借助高速順序引擎，用戶可實現SMU之間的同步或與其他儀器的同步，提高測試效率。
3. 靈活性：可自定義PXIe-4143對任何負載的響應，實現具有穩定性和小瞬態的響應，滿足不同測試場景的需求。
4. 高密度：在單個4U PXI機箱上最多可有68個通道，提供業界領先的通道密度。
5. 模塊化：模塊化PXI平臺使您能夠通過PXI背板觸發這些源測量單元SMU，以同步與其他儀器的測量，包括高速數字I/O儀器、射頻分析儀、發生器、高速數字化儀等。

四、應用領域

PXIe-4143 4通道精密PXI源測量單元廣泛應用于各種自動化測試和實驗室特性分析應用中，包括但不限于：

• 半導體測試：如MEMS系統測試、開短路檢測、RF集成電路（RFIC）供電等。
• 電子元件測試：如電阻、電容、電感等元件的測試。
• 電路板測試：在電路板級別的測試中提供精確的電源和測量功能。
• 實驗室研究：在實驗室環境中進行各種電子器件和系統的特性分析。

The PXIe-4143 4-channel Precision PXI Source Measurement Unit (SMU) is a high-performance testing instrument designed specifically for high pin count applications. The following is a detailed introduction to the product:

1、 Product Overview

Brand: National Instruments (NI)

Model: PXIe-4143

Type: 4-channel precision PXI source measurement unit

2、 Technical specifications

Number of channels: 4 identical SMU channels, suitable for parallel testing.

Voltage range: ± 24V, meeting various testing requirements.

Current range: ± 150mA, suitable for low-power applications.

Current sensitivity: High current measurement sensitivity, very suitable for measuring various current characteristics including reactive current.

Operation mode: Adopting a four quadrant operation mode, each channel integrates remote (4-wire) sensing function to ensure measurement accuracy.

3、 Product Features

High precision: Integrated sensing function and high current measurement sensitivity provide high-precision measurement results.

High speed: With the help of a high-speed sequential engine, users can achieve synchronization between SMUs or with other instruments, improving testing efficiency.

Flexibility: The PXIe-4143 can be customized to respond to any load, achieving stable and small transient responses to meet the needs of different testing scenarios.

High density: There can be up to 68 channels on a single 4U PXI chassis, providing industry-leading channel density.

Modularization: The modular PXI platform enables you to trigger these source measurement units (SMUs) through the PXI backplane to synchronize measurements with other instruments, including high-speed digital I/O instruments, RF analyzers, generators, high-speed digitizers, etc.

4、 Application Fields

The PXIe-4143 4-channel precision PXI source measurement unit is widely used in various automated testing and laboratory characteristic analysis applications, including but not limited to:

Semiconductor testing: such as MEMS system testing, open/short circuit detection, RF integrated circuit (RFID) power supply, etc.

Electronic component testing: testing of components such as resistors, capacitors, inductors, etc.

Circuit board testing: Provide precise power and measurement functions in circuit board level testing.

Laboratory research: Conducting characteristic analysis of various electronic devices and systems in a laboratory environment.
