GE/Fanuc發那科的VMIVME-2540 VMIC智能計數器控制器是一款高性能的設備，具有多項特點和功能。
首先，VMIVME-2540具有高性能的計數能力，能夠計算多達4個千兆事件，顯示出其卓越的處理能力和計數精度。其次，它配備了24個離散輸出通道，這些通道能夠通過各種板載跳線模塊選項進行編程，這種靈活性使得設備能夠適應多種不同的輸出需求。每個輸出通道被設計為提供12位分辨率，這意味著輸出信號具有更高的精度和穩定性。
此外，VMIVME-2540由六個可編程系統時序控制器（STCs）組成，每個STC為ICC提供四個高速計數器/波形合成接口，為VMIVME-2540提供24通道數字測量和控制。這些STC計數器可以單獨配置，也可以最多配置4個，以實現各種測量和控制功能。板載的68HC000 CPU直接配置和管理每個STC接口，使得VMEbus主機接口提升到硬件級別之上。
VMIVME-2540還具有高速、易于使用的網絡功能，單模式下節點間距離高達10,000米，數據傳輸速率可達29.5兆字節/秒（或14.8兆字節/秒，帶冗余傳輸）。此外，該板還符合單槽VME標準，并帶有中斷的VMIC VMIVME-5588高速反射存儲器支持錯誤檢測以及抑制錯誤的冗余傳輸模式。
GE/Fanuc's VMIVME-2540 VMIC Intelligent counter controller is a high performance device with a number of features and functions.
First, the VMIVME-2540 has a high performance counting capability, capable of calculating up to 4 gigabit events, showing its superior processing power and counting accuracy. Second, it is equipped with 24 discrete output channels that can be programmed with various on-board jumper module options, and this flexibility allows the device to adapt to many different output needs. Each output channel is designed to provide 12-bit resolution, which means that the output signal has higher accuracy and stability.
In addition, the VMIVME-2540 consists of six programmable System Timing controllers (STCs), each of which provides four high-speed counter/waveform synthesis interfaces for the ICC, providing 24-channel digital measurement and control for the VMIVME-2540. These STC counters can be configured individually or up to four to enable a variety of measurement and control functions. The onboard 68HC000 CPU directly configters and manages each STC interface, elevating the VMEbus host interface above the hardware level.
The VMIVME-2540 also features high-speed, easy-to-use networking capabilities with distances up to 10,000 meters between nodes in a single mode and data transfer rates up to 29.5 megabytes per second (or 14.8 megabytes per second with redundancy). In addition, the board complies with the single-slot VME standard and comes with an interrupted VMIC VMIVME-5588 high-speed reflection memory that supports error detection as well as redundant transmission modes that suppress errors.
