IC693PWR321L 高容量電源模塊增強Fanuc90-30 PLC系列的處理能力
GE Fanuc IC693PWR321模塊是90-30系列的電源模塊。它增強了Fanuc系列90-30 PLC的處理能力。它位于底板最左側的插槽中。它的額定功率為30瓦。它可以使用交流和DC電源。設備的輸入電壓源必須具有85至264伏交流電或100至300伏DC的電壓范圍。它提供不同的電壓輸出:5伏DC，24伏DC電壓為電路供電，以及一個隔離的24伏DC電壓源，由一些模塊用來提供外部電源。它有一個4安培的峰值浪涌電流，最大250毫秒。這種可編程控制器電源設備具有堅固的結構，并配有電池。
IC693PWR321模塊完全兼容任何型號的CPU。電源模塊通過了cULus和CE標準認證。它設計用于1級2區額定環境。IC693PWR321模塊帶有電源限制功能，在直接短路時可以立即保護硬件。電源裝置配有6個用于操作員連接的端子。它具有增強的診斷功能，可為操作員跟蹤所有事件和更新。作為一種保護措施，電源設備內置了智能開關保險絲。對于通信，IC693PWR321模塊配有一個RS-485串行端口。串行端口可用于連接不同的外圍設備和CPU/計算機。
IC693PWR321能夠使用交流或DC電源供電。該電源的交流輸入電壓范圍為85-264VAC，標稱值為120-240VAC。對于DC電源電壓，可接受的電壓范圍為100-300 VDC，標稱值為125VDC。對于交流輸入，其輸入功率要求為90伏安;對于DC輸入，其輸入功率要求為50瓦。它可以承受持續時間為250 ms的4A峰值浪涌電流。
lC693PWR321輸出功率能力包括最大15瓦，用于5 VDC和24VDC繼電器操作;24伏直流繼電器最大15瓦，24伏直流隔離繼電器最大20瓦。該電源的輸出電壓為5.0 VDC至5.2 VDC，標稱值為5.1VDC24伏直流至28伏直流，用于24伏直流繼電器;21.5VDC至2BVDC，用于隔離24VDC操作。它具有6.4VDC至7VDC的過壓保護和4A的過流保護，最大保持時間為20 ms
IC693PWR321還有一(1)個9針sub-D連接器RS485兼容串行端口。它配有一個內部保險絲，GE目錄號為44A724627-109。該保險絲可能來自第三方供應商。適用的替代保險絲是巴斯曼-215-002(GDC-2或GMC-2)和小保險絲-239-002。
The GE Fanuc IC693PWR321 is a power module of the 90-30 series. It enhances the processing power of the Fanuc series 90-30 PLCS. It is located in the leftmost slot of the bottom plate. It is rated at 30 watts. It can use AC and DC power supplies. The input voltage source of the device must have a voltage range of 85 to 264 volts AC or 100 to 300 volts DC. It offers different voltage outputs :5 volt DC, 24 volt DC voltage to power the circuit, and an isolated 24 volt DC voltage source used by some modules to provide external power. It has a peak surge current of 4 amps for a maximum of 250 milliseconds. This programmable controller power device has a robust construction and is equipped with a battery.
The IC693PWR321 module is fully compatible with any type of CPU. The power module has passed the cULus and CE standards. It is designed for use in Level 1, zone 2 rated environments. The IC693PWR321 module comes with a power limiting function that instantly protects the hardware in the event of a direct short circuit. The power unit is equipped with 6 terminals for operator connection. It has enhanced diagnostic capabilities that keep track of all events and updates for the operator. As a protective measure, smart switching fuses are built into the power supply. For communication, the IC693PWR321 module is equipped with an RS-485 serial port. Serial ports can be used to connect different peripherals and cpus/computers.
The IC693PWR321 can be powered by AC or DC power. The AC input voltage range of this power supply is 85-264VAC and the nominal value is 120-240VAC. For DC supply voltages, the acceptable voltage range is 100-300 VDC, with a nominal value of 125VDC. For AC input, the input power requirement is 90 volt-ampere; For DC inputs, the input power requirement is 50 watts. It can withstand 4A peak surge current with a duration of 250 ms.
The lC693PWR321 output power capability includes up to 15 watts for 5 VDC and 24VDC relay operation; The 24-volt DC relay has a maximum of 15 watts, and the 24-volt DC isolation relay has a maximum of 20 watts. The power supply has an output voltage of 5.0VDC to 5.2VDC and a nominal value of 5.1VDC24 VDC to 28 VDC for 24 volt DC relays; 21.5VDC to 2BVDC, used to isolate 24VDC operations. It has overvoltage protection from 6.4VDC to 7VDC and overcurrent protection from 4A, with a maximum hold time of 20 ms
The IC693PWR321 also has one (1) 9-pin sub-D connector RS485 compatible serial port. It comes with an internal fuse and GE catalog number 44A724627-109. The fuse may come from a third party supplier. Suitable alternative fuses are Bussman -215-002(GDC-2 or GCC-2) and Small fuse -239-002.
如果您需要其他信息/幫助，請隨時與我們聯系。
銷售部經理:羅經理
QQ:3248602330
手機/微信同號: +86-18030183032
郵箱:3248602330qq.com
選擇深圳雄霸:IC693PWR321L 高容量電源模塊增強Fanuc90-30 PLC系列的處理能力
深圳雄霸工控自動化有限公司提供優質的新零件以及我們攜帶的所有產品的質量。我們提供所有產品至少一年保修。
接受退貨，但需要補貨
可能會收取費用。深圳雄霸工控自動有限公司的150，000名滿意客戶證明了我們最優質的服務。
您的選擇，我們的服務
您的信任，我們的品質
您的滿意，我們的追求
雄霸電子商務有限公司成立超過15年，致力于提供最優質的客戶服務在業內。作為工廠自動化批發分銷商，我們在全球范圍內提供和交付產品。
If you need additional information/assistance, please feel free to contact us.
Sales Manager: Mr. Luo
QQ:3248602330
Mobile phone/wechat number: +86-18030183032
Email :3248602330qq.com
Choose Shenzhen Xiunba :IC693PWR321L high capacity power module to enhance the processing power of Fanuc90-30 PLC series
Shenzhen Xiongba Industrial Control Automation Co., Ltd. provides quality new parts as well as the quality of all the products we carry. We offer a minimum one year warranty on all products.
Returns are accepted, but restocking is required
A fee may apply. The 150,000 satisfied customers of Shenzhen Xiongba Industrial Control Automation Co., Ltd. testify to our highest quality service.
Your choice, our service
Your trust, our quality
Your satisfaction, our pursuit
Xiongba E-commerce Co., Ltd. was established for more than 15 years and is committed to providing the best quality customer service in the industry. As a wholesale factory automation distributor, we provide and deliver products worldwide.
