GE美國 IC754VSL06CTD-KG 數字量輸出模塊

GE美國 IC754VSL06CTD-KG 數字量輸出模塊

GE美國 IC754VSL06CTD-KG 數字量輸出模塊

GE美國 IC754VSL06CTD-KG 數字量輸出模塊是一款由通用電氣（GE）制造的高性能模塊，屬于QuickPanel+系列。以下是對該模塊的詳細介紹：

一、產品概述

• 品牌：GE（通用電氣）
• 型號：IC754VSL06CTD-KG
• 類型：數字量輸出模塊
• 系列：QuickPanel+

二、主要功能特點

1. 人機交互界面：
• IC754VSL06CTD-KG是一款基于一體化微機的7英寸寬屏TFT彩色觸摸屏終端，采用800 x 480像素WVGA分辨率設計，并具有LED背光顯示屏。
• 它是一款投射電容式觸摸屏，非常靈活，具有高級通信選項，是工業控制系統的理想接口。
2. 硬件配置：
• 在面板上運行整個系統的微處理器是ARM 1GHz Cortex A8 - Freescale i.MX535。
• 內存容量包括512MB RAM內存、512 KB SRAM內存（帶電池備份）和256MB ROM內存。
• 安裝了Microsoft Windows 7 Embedded Compact（32位）操作系統。
3. 編程與連接：
• 用戶必須獲得Proficy View Machine Edition軟件（Proficy Machine Edition的一部分）來對面板上使用的應用程序進行編程。
• 編程連接可通過RS232/RS485通訊端口和HMI-CAB通訊電纜實現，或者通過閃存卡端口（SD卡）訪問面板進行編程。
4. 電源與能耗：
• 連接到24伏直流電源時，最大消耗15瓦。
• 輸入電壓在24V DC ±20%范圍內是可接受的。
5. 接口與連接：
• 位于輸入端子旁邊的是USB、以太網和RS-232連接器。
• 支持RS232/RS485通訊端口，以及一個10BaseT/100BaseTx以太網端口和一個單型雙緊湊型閃存卡端口。
6. 環境適應性：
• 該終端安裝在IP65等級的外殼中，尺寸為7.56 × 5.39 × 1.42英寸（192 × 137 × 36毫米），重量約為0.800公斤（1.76磅）。
• 工作溫度范圍為0至50攝氏度，存儲溫度范圍為-20至60攝氏度。

三、應用場景

IC754VSL06CTD-KG數字量輸出模塊適用于各種工業生產環境，作為工業控制系統的關鍵組件，它能夠提供穩定、可靠的人機交互和數據傳輸功能，支持各種復雜工業流程的監控和控制。

The GE IC754VSL06CTD-KG digital output module is a high-performance module manufactured by General Electric (GE) and belongs to the QuickPanel+series. The following is a detailed introduction to the module:

1、 Product Overview

Brand: GE (General Electric)

Model: IC754VSL06CTD-KG

Type: Digital output module

Series: QuickPanel+

2、 Main functional features

Human computer interaction interface:

IC754VSL06CTD-KG is a 7-inch widescreen TFT color touch screen terminal based on an integrated microcomputer, designed with an 800 x 480 pixel WVGA resolution and featuring an LED backlit display screen.

It is a projection capacitive touch screen that is very flexible and has advanced communication options, making it an ideal interface for industrial control systems.

Hardware configuration:

The microprocessor that runs the entire system on the panel is ARM 1GHz Cortex A8 Freescale i.MX535.

The memory capacity includes 512MB RAM memory, 512 KB SRAM memory (with battery backup), and 256MB ROM memory.

Installed Microsoft Windows 7 Embedded Compact (32-bit) operating system.

Programming and Connection:

Users must obtain Proficy View Machine Edition software (part of Proficy Machine Edition) to program the applications used on the panel.

Programming connection can be achieved through RS232/RS485 communication port and HMI-CAB communication cable, or programming can be accessed through the flash card port (SD card) to access the panel.

Power and energy consumption:

When connected to a 24V DC power supply, the maximum power consumption is 15 watts.

An input voltage within the range of 24V DC ± 20% is acceptable.

Interface and Connection:

Next to the input terminal are USB, Ethernet, and RS-232 connectors.

Supports RS232/RS485 communication ports, as well as one 10BaseT/100BaseTx Ethernet port and one single type dual compact flash card port.

Environmental adaptability:

The terminal is installed in an IP65 rated enclosure, measuring 7.56 x 5.39 x 1.42 inches (192 x 137 x 36 millimeters) and weighing approximately 0.800 kilograms (1.76 pounds).

The working temperature range is 0 to 50 degrees Celsius, and the storage temperature range is -20 to 60 degrees Celsius.

3、 Application scenarios

The IC754VSL06CTD-KG digital output module is suitable for various industrial production environments. As a key component of industrial control systems, it can provide stable and reliable human-machine interaction and data transmission functions, supporting monitoring and control of various complex industrial processes.
