PLC主要應用的領域
1.開關量邏輯控制
取代傳統的繼電器電路,實現邏輯控制、順序控制,既可用于單臺設備的控制,也可用于多機群控及自動化流水線。如注塑機、印刷機、訂書機械、組合機床、磨床、包裝生產線、電鍍流水線等。
2.工業過程控制
在工業生產過程當中,存在一些如溫度、壓力、流量、液位和速度等連續變化的量(即模擬量),PLC采用相應的A/D和D/A轉換模塊及各種各樣的控制算法程序來處理模擬量,完成閉環控制。PID調節是一般閉環控制系統中用得較多的一種調節方法。過程控制在冶金、化工、熱處理、鍋爐控制等場合有非常廣泛的應用。
3.運動控制
PLC可以用于圓周運動或直線運動的控制。一般使用專用的運動控制模塊,如可驅動步進電機或伺服電機的單軸或多軸位置控制模塊,廣泛用于各種機械、機床、機器人、電梯等場合。
4.?dāng)?shù)據處理
PLC具有數學運算(含矩陣運算、函數運算、邏輯運算)、數據傳送、數據轉換、排序、查表、位操作等功能,可以完成數據的采集、分析及處理。數據處理一般用于如造紙、冶金、食品工業中的一些大型控制系統。
5.通信及聯網
PLC通信含PLC間的通信及PLC與其它智能設備間的通信。隨著工廠自動化網絡的發展,現在的PLC都具有通信接口,通信非常方便。

DSP的性能受其對存儲器子系統的管理能力的影響。如前所述,MAC和其它一些信號處理功能是DSP器件信號處理的基本能力,快速M(fèi)AC執行能力要求在每個指令周期從存儲器讀取一個指令字和兩個數據字。有多種方法實現這種讀取。比如,使用多接口存儲器(允許在每個指令周期內對存儲器多次訪問)、分離指令和數據存儲器(“哈佛”結構及其派生類)以及指令緩存(允許從緩存讀取指令而不是存儲器,從而將存儲器空閑出來用作數據讀?。?span style="max-width: 100%; text-indent: 2em;">另外要注意所支持的存儲器空間的大小。許多定點DSP的主要目標市場是嵌入式應用系統,在這種應用中存儲器一般較小,所以這種DSP器件具有小到中等片上存儲器(4K到64K字左右),備有窄的外部數據總線。另外,絕大多數定點DSP的地址總線小于或等于16位,因而可外接的存儲器空間受到限制一些浮點DSP的片上存儲器很小,甚至沒有,但外部數據總線寬。例如TI公司的TMS320C30只有6K片上存儲器,外部總線為24位,13位外部地址總線。而ADI的ADSP2-21060具有4Mb的片上存儲器,可以多種方式劃分為程序存儲器和數據存儲器。選擇DSP時,需要根據具體應用對存儲空間大小以及對外部總線的要求來選擇。

DSP processors and devices such as Intel, Pentium, or powerGeneral purpose processors (GPPS) of PC have great differences. These differences arise from the fact that the structure and instructions of DSPs are specially designed and developed for signal processing. It has the following characteristics.In order to effectively complete multiplication and accumulation operations such as signal filtering, the processor must perform effective multiplication operations. GPPS was not originally designed for heavy multiplication operations. The first major technical improvement that distinguishes DSPs from early GPPS is the addition of specialized hardware and explicit MAC instructions that can perform single cycle multiplication operations.Traditional GPPS use von Neumann storage structure, in which a storage space is connected to the processor core through two buses (an address bus and a data bus). This structure cannot meet the requirement that MAC must access the memory four times in an instruction cycle. DSPs generally use Harvard structure, in which there are two storage spaces: program storage space and data storage space. The processor core is connected to these storage spaces through two sets of buses, allowing two simultaneous accesses to the memory. This arrangement doubles the bandwidth of the processor. In Harvard architecture, sometimes a larger storage bandwidth is achieved by adding a second data storage space and bus. Modern high-performance GPPS usually have two on-chip cache memories, one for storing data and one for storing instructions. Theoretically, this dual on-chip cache and bus connection is equivalent to the Harvard structure. However, GPPS use control logic to determine which data and instruction words reside in the on-chip cache, which is usually not seen by the programmer. In DSPs, the programmer can clearly control which data and instructions are stored in the on-chip storage unit or cache.
