ABB 216EA61B HESG448230R1/G 是一款高性能的模擬量輸入模塊，專為工業自動化和電力系統設計。它作為 ABB S800 I/O 系統的一部分，能夠精確采集電流、電壓等模擬量信號，廣泛應用于電力系統保護和工業過程控制。
| 參數名稱 | 參數值 |
|---|---|
| 產品型號 | 216EA61B HESG448230R1/G |
| 制造商 | ABB |
| 產品類型 | 模擬量輸入模塊 |
| 輸入通道數 | 8 路（可擴展至 16 路，需搭配 216GW61 模塊） |
| 輸入信號類型 | 4-20mA、0-20mA、0-10V |
| 額定輸入電壓 | 24V DC（±20%） |
| 測量精度 | ±0.1% FS |
| 隔離電壓 | 500V AC（通道間） |
| 采樣頻率 | 200Hz / 通道 |
| 通信協議 | B448C 并行總線（兼容 HART 協議） |
| 工作溫度范圍 | -20°C 至 +60°C |
| 存儲溫度范圍 | -40°C 至 +85°C |
| 相對濕度 | 5-95%（無冷凝） |
| 物理尺寸 | 35mm × 100mm × 150mm |
| 重量 | 0.26kg |
| 防護等級 | IP20 |
| 認證 | CE、UL、CSA |
ABB 216EA61B HESG448230R1/G protection module
product overview
ABB 216EA61B HESG448230R1/G is a high-performance analog input module designed specifically for industrial automation and power systems. As part of the ABB S800 I/O system, it can accurately collect analog signals such as current and voltage, and is widely used in power system protection and industrial process control.
technical specifications
Parameter Name Parameter Value
Product model 216EA61B HESG448230R1/G
Manufacturer ABB
Product Type Analog Input Module
8 input channels (expandable to 16 channels, requiring 216GW61 module)
Input signal types 4-20mA, 0-20mA, 0-10V
Rated input voltage 24V DC (± 20%)
Measurement accuracy ± 0.1% FS
Isolation voltage 500V AC (between channels)
Sampling frequency 200Hz/channel
Communication protocol B448C parallel bus (compatible with HART protocol)
Working temperature range -20 ° C to+60 ° C
Storage temperature range -40 ° C to+85 ° C
Relative humidity 5-95% (no condensation)
Physical dimensions 35mm × 100mm × 150mm
Weight 0.26kg
Protection level IP20
Certification CE, UL, CSA
Main features and advantages
High precision signal acquisition: Built in 16 bit high-precision ADC converter, combined with software adjustable filtering function (0.1-100ms), effectively suppresses high-frequency interference and signal noise, ensuring measurement accuracy of ± 0.1% FS.
Anti interference design: Adopting optoelectronic isolation technology (500V AC channel isolation) and redundant power supply design, it can work stably in strong electromagnetic interference environments.
Wide temperature adaptability: The working temperature range is -20 ° C to+60 ° C, suitable for high temperature, high dust, and vibration scenarios.
Flexible system integration capability: Through B448C parallel bus and protection processing unit 216VC624, data exchange is achieved, compatible with PROFIBUS DP and HART communication protocols, and can be seamlessly integrated into ABB 800xA extended automation systems and third-party control systems.
Modular design: Supports hot swappable functionality, allowing for maintenance and replacement while the system is running, significantly reducing downtime.
application area
Power system: used for equipment monitoring and protection in power plants and substations, such as real-time monitoring of key equipment such as generators and transformers.
Petrochemical industry: monitoring and controlling key parameters in the production process, such as temperature, pressure, flow rate, etc.
Metallurgy and Material Processing: Used for monitoring and controlling various equipment in the production process.
