ABB CI871AK01 通訊控制器
產品概述
ABB CI871AK01（訂貨號：3BSE092693R1）是一款高性能的工業通信接口模塊，
專為 ABB 800xA DCS（分布式控制系統）和 AC 800M 控制系統設計。它作為控制器與外部設備（如變頻器、遠程 I/O 模塊）之間的通信橋梁，實現高速數據交換。
技術規格
通信協議：支持 Modbus TCP/IP、PROFIBUS-DP（DP-V0/DP-V1）、PROFINET IO。
通信速率：最高 12 Mbps，支持自動波特率檢測。
接口類型：
1 個 PROFIBUS D-sub 9 針接口。
RJ45 以太網接口（僅 CH1 通道有效），支持 V2.3/V2.4 標準。
安裝方式：DIN 導軌或 800xA 專用機架。
電源：由底板供電。
工作溫度范圍：-25°C 至 +70°C。
防護等級：IP20。
尺寸：59 mm（寬）× 186 mm（高）× 127.5 mm（深）。
重量：0.7 kg。
功能特點
高速數據傳輸：支持 Modbus TCP/IP 協議，實現快速、穩定的數據交換，適用于對實時性要求高的工業場景。
多協議兼容：兼容多種工業標準協議，適用于不同的自動化環境。
遠程管理：支持遠程監測和診斷，提高系統運維效率。
靈活擴展：模塊化設計，便于維護和升級，可擴展性強。
工業級可靠性：具備較強的抗干擾能力，適用于嚴苛的工業環境。
冗余電源設計：內置 DC/DC 轉換器，確保供電穩定性。
集成操作系統：集成 NuttX 嵌入式操作系統，處理能力強大，適用于復雜算法與實時監控。
應用領域
過程控制：廣泛應用于石油、化工、制藥、冶金等行業的過程自動化。
電力系統：適用于發電廠、變電站等場景，實現遠程監測和數據采集。
制造自動化：用于智能制造、工業機器人控制等，提高生產效率。
水處理系統：在污水處理、自來水廠等環境中，實現遠程監測和數據通信。
ABB CI871AK01 Communication Controller
product overview
ABB CI871AK01 (order number: 3BSE092693R1) is a high-performance industrial communication interface module designed specifically for ABB 800xA DCS (distributed control system) and AC 800M control systems. It serves as a communication bridge between the controller and external devices such as frequency converters and remote I/O modules, enabling high-speed data exchange.
technical specifications
Communication protocol: Supports Modbus TCP/IP, PROFIBUS-DP (DP-V0/DP-V1), and PROFINET IO.
Communication speed: up to 12 Mbps, supports automatic baud rate detection.
Interface type:
1 PROFIBUS D-sub 9-pin interface.
RJ45 Ethernet interface (only valid for CH1 channel), supporting V2.3/V2.4 standards.
Installation method: DIN rail or 800xA dedicated rack.
Power supply: Powered by the motherboard.
Working temperature range: -25 ° C to+70 ° C.
Protection level: IP20.
Dimensions: 59 mm (width) x 186 mm (height) x 127.5 mm (depth).
Weight: 0.7 kg.
Functional Features
High speed data transmission: Supports Modbus TCP/IP protocol to achieve fast and stable data exchange, suitable for industrial scenarios with high real-time requirements.
Multi protocol compatibility: Compatible with multiple industrial standard protocols, suitable for different automation environments.
Remote management: supports remote monitoring and diagnosis to improve system operation and maintenance efficiency.
Flexible Expansion: Modular design, easy to maintain and upgrade, strong scalability.
Industrial grade reliability: With strong anti-interference ability, suitable for harsh industrial environments.
Redundant power supply design: Built in DC/DC converter to ensure power supply stability.
Integrated operating system: Integrated with NuttX embedded operating system, with powerful processing capabilities, suitable for complex algorithms and real-time monitoring.
application area
Process control: widely used in process automation in industries such as petroleum, chemical, pharmaceutical, metallurgy, etc.
Power system: suitable for scenarios such as power plants and substations, enabling remote monitoring and data collection.
Manufacturing automation: used for intelligent manufacturing, industrial robot control, etc., to improve production efficiency.
Water treatment system: It enables remote monitoring and data communication in environments such as sewage treatment and water treatment plants.
