WOODWARD 8200-1302 工業數字調速器
產品概述
Woodward 8200-1302 是一款高性能的數字調速器，屬于 Woodward 505D 系列，專為工業和能源領域的精密控制應用設計。它廣泛應用于發電、石油和天然氣、水處理、造紙、鋼鐵和采礦等行業。
技術規格
輸入電壓范圍：18-36V DC 或 24V DC。
工作溫度范圍：-22°F 至 158°F（-30°C 至 70°C）。
存儲溫度范圍：-40°C 至 +125°C。
顯示屏：8.4 英寸液晶顯示器。
外殼類型：IACS UR E10（商用船用），具有 ATEX、IP-54 和污染等級 3 認證。
通信接口：支持 Modbus RTU、CAN、Ethernet 等協議。
模擬輸入：8 個通道，可配置為 27 種功能中的任何一個。
輸出：兩個 4-20 mA 控制輸出和八個 Form-C 繼電器觸點輸出。
冗余設計：兩個冗余速度輸入，可接受磁性拾取裝置、渦流探頭或接近探頭。
控制模式：提供配置模式、操作模式和校準模式。
防護等級：IP54。
功能特點
高精度控制：速度精度 ±0.05%，響應時間 <1 秒。
多種控制模式：包括速度控制、功率控制、負載控制等。
完善的保護功能：過速、欠速、過載和欠載保護。
靈活的配置：支持 PID 控制算法，可定制邏輯控制。
智能通信能力：支持多種通信協議，便于與其他設備集成。
自診斷功能：能夠檢測設備問題并提供相關信息，便于維護和修復。
應用領域
發電行業：控制發電機、汽輪機、燃氣輪機等設備的轉速。
石油和天然氣：控制壓縮機、泵站等設備的轉速。
化工行業：控制反應釜轉速。
造紙行業：控制紙機驅動。
船舶行業：控制推進系統。
其他工業應用：如自動化設備、能源管理和 HVAC 系統。
前面板設計
緊急跳閘鍵：用于緊急停機。
導航十字鍵：用于操作和調整。
軟鍵命令：用于執行特定操作。
LED 指示燈：顯示控制和硬件狀態信息。
優勢
模塊化設計：易于擴展和維護。
高可靠性：采用冗余設計，確保系統穩定運行。
智能化：支持多種通信協議和遠程監控功能。
Woodward 8200-1302 industrial digital governor
Product overview
Woodward 8200-1302 is a high-performance digital governor, belonging to Woodward 505d series, designed for precision control applications in the industrial and energy fields. It is widely used in power generation, oil and gas, water treatment, paper making, steel and mining industries.
technical specifications
Input voltage range: 18-36V DC or 24V DC.
Operating temperature range: -22 ° f to 158 ° f (-30 ° C to 70 ° C).
Storage temperature range: -40 ° C to+125 ° C.
Display: 8.4 inch LCD.
Enclosure type: IACS ur E10 (commercial marine), with ATEX, ip-54 and pollution level 3 certification.
Communication interface: support Modbus RTU, can, Ethernet and other protocols.
Analog input: 8 channels, which can be configured as any of 27 functions.
Outputs: two 4-20 ma control outputs and eight Form-C relay contact outputs.
Redundant design: two redundant speed inputs, which can accept magnetic pickup device, eddy current probe or proximity probe.
Control mode: configuration mode, operation mode and calibration mode are provided.
Protection grade: IP54.
Functional features
High precision control: speed accuracy ± 0.05%, response time<1 second.
Various control modes: including speed control, power control, load control, etc.
Perfect protection function: over speed, under speed, overload and under load protection.
Flexible configuration: it supports PID control algorithm and can customize logic control.
Intelligent communication capability: support a variety of communication protocols to facilitate integration with other devices.
Self diagnosis function: it can detect equipment problems and provide relevant information for maintenance and repair.
application area
Power generation industry: control the speed of generators, steam turbines, gas turbines and other equipment.
Oil and natural gas: control the speed of compressor, pump station and other equipment.
Chemical industry: control the speed of reaction kettle.
Paper industry: control paper machine drive.
Shipbuilding Industry: control propulsion system.
Other industrial applications: such as automation equipment, energy management and HVAC systems.
Front panel design
Emergency trip key: used for emergency shutdown.
Navigation cross key: used for operation and adjustment.
Soft key commands: used to perform specific operations.
LED indicator: display control and hardware status information.
advantage
Modular design: easy to expand and maintain.
High reliability: redundancy design is adopted to ensure the stable operation of the system.
Intelligentization: support a variety of communication protocols and remote monitoring functions.
