產品介紹
產品參數:1764-24BWA MicroLogix 1500可編程邏輯數字控制器(PLC)
Allen-Bradley 1764-245WA是MicroLogix 1500可編程邏輯控制器(PLC)的一部分。該部件號是容納必要的MicroLogix 1500模塊(如處理器和內存模塊)的基本單元。當與1764處理器—起安裝時，基本單元成為功能PLC。
1764-24BWA是一個可獨立更換的裝置，允許最大化嵌入式/O選項，同時最小化庫存成本。它包含電源、通信端口以及嵌入式輸入和輸出。公告1764-24BWA基本單元允許通過其通道0端口與其他設備進行高級通信。它充當應用程序所需的擴展I/O接口。它帶有八個標準和四個快速24伏DC輸入和四個20千赫高速輸入。1764-24BWA基礎需要處理器才能工作，它與1764-LRP或1764-LSP兼容。
它有一條120到240伏的交流額定電源線和12個繼電器(其中兩個是隔離的)。它的功耗為88 VA，最大負載功率為22，電源電壓為85至265伏交流電，頻率為47至63赫茲。它還有一個24伏DC功率傳感器，額定最大電容為400毫安或400華氏度，這是其他基本單元所不具備的強大功能。1764-24BWA底座擁有CE、C-Tick、UL、 c-UL和級2區危險場所操作的產品認證。它與Bulletin 1764處理器一起構成完整的控制器。這種組件不應該安裝在電力線附近。
Allen-Bradley 1764L.24BWA是MicroLogix 1500基本單元。該基本單元提供了模塊化外殼。此基本單元可安裝MicroLogix處理器，如1764-LSP和1764-IRP。此外，此基本單元可以安裝數據訪問工具(DAT ).如1764-DAT。安裝到基本單元的其他兼容模塊是內存模塊和實時時鐘。
1764-24BWA MicroLogix 1500基本裝置具有集成的八(8個24VDC離散輸入、四(4)個高速輸入和十二(12)個繼電器輸出。該基本裝置在安裝過程中需要最小的面板空間。它可以使用DIN導軌或安裝螺釘進行安裝?？刂破鞲鱾?cè)的建議安裝間隙為兩(2)英寸。這是為了確保足夠的通風。
1764-24BWA支持安裝擴展模塊，以增強基本單元的集成功能。兼容的擴展模塊是1769緊湊型I/O模塊。這些模塊可以作為本地/O模塊直接安裝。此外，該基本單元還通過擴展機架支持?jǐn)U展配置。這是通過使用1769擴展電纜實現的。
集成通信端口支持全雙工或半雙工DF1協議接口。它可與高級接口轉換器(AIC) are 1761-NET-AIC、1761-NET-ENI接口，或通過使用DeviceNet掃描儀模塊1769-SDN與DeviceNet網絡接口。該轉換器也可用于復用基本單元上的串行端口，從而允許人機界面(HMI)、監控和數據采集(SCADA).編程工作站、設備轉換器和網關同時通信。
●所有產品圖片均為真實人物，如果您需要更多照片，請聯系我們。
●所有售出的產品質量保證一年，如果有質量問題我們可以給您更換或退回。
●我們是中國最大的工控產品供應商，如果您需要其他類型的產品，請向我們咨詢，我們會立即給您答復。
o如果您購買的不止一個，我們會給您折扣，如果您收到價格，請與我們聯系，我們將盡力讓您滿意，我們的客戶來自世界各地，歡迎來到中國。
Product introduction
Product parameters :1764-24BWA MicroLogix 1500 Programmable Logic Digital Controller (PLC)
The Allen-Bradley 1764-245WA is part of the MicroLogix 1500 Programmable Logic Controller (PLC). This part number is the basic unit that houses the necessary MicroLogix 1500 modules, such as the processor and memory modules. When installed with a 1764 processor, the base unit becomes a functional PLC.
The 1764-24BWA is an independently replaceable unit that allows to maximize embedded /O options while minimizing inventory costs. It contains a power supply, communication ports, and embedded inputs and outputs. Bulletin 1764-24BWA Base unit allows advanced communication with other devices through its channel 0 port. It acts as the extended I/O interface required by the application. It comes with eight standard and four fast 24 volt DC inputs and four 20 KHZ high-speed inputs. The 1764-24BWA base requires a processor to work and is compatible with 1764-LRP or 1764-LSP.
It has a 120 to 240 volt AC rated power cord and 12 relays (two of which are isolated). It has a power consumption of 88 VA, a maximum load power of 22, a supply voltage of 85 to 265 volts AC, and a frequency of 47 to 63 Hertz. It also has a 24-volt DC power sensor rated for a maximum capacitance of 400 MA or 400 degrees Fahrenheit, a powerful feature not found in other base units. The 1764-24BWA base is certified for CE, C-Tick, UL, c-UL and Class 2 Hazardous Site operation. Together with the Bulletin 1764 processor, it forms a complete controller. Such components should not be installed near power lines.
Allen-Bradley 1764L.24BWA is the MicroLogix 1500 base unit. The basic unit is provided with a modular housing. This base unit can be installed with MicroLogix processors such as 1764-LSP and 1764-IRP. In addition, this base unit can install data access tools (DAT). Such as 1764-DAT. Other compatible modules installed to the base unit are the memory module and the real-time clock.
The 1764-24BWA MicroLogix 1500 base unit has integrated eight (8) 24VDC discrete inputs, four (4) high-speed inputs, and twelve (12) relay outputs. This basic unit requires minimal panel space during installation. It can be mounted using DIN rails or mounting screws. The recommended installation clearance on each side of the controller is two (2) inches. This is to ensure adequate ventilation.
1764-24BWA supports the installation of expansion modules to enhance the integration of the base unit. The compatible expansion module is the 1769 compact I/O module. These modules can be installed directly as local /O modules. In addition, the base unit supports extended configurations through extension racks. This is achieved by using the 1769 extension cable.
The integrated communication port supports full-duplex or half-duplex DF1 protocol interfaces. It can interface with the Advanced Interface Converter (AIC) are 1761-NET-AIC, 1761-NET-ENI, or with the DeviceNet network by using the DeviceNet scanner module 1769-SDN. The converter can also be used to reuse serial ports on the base unit, allowing for human machine interface (HMI), monitoring and data acquisition (SCADA). Programming workstations, device converters, and gateways communicate simultaneously.
● All product images are real people, if you need more photos, please contact us.
● The quality of all sold products is guaranteed for one year, if there is a quality problem, we can give you a replacement or return.
● We are the largest supplier of industrial control products in China, if you need other types of products, please contact us, we will reply to you immediately.
o If you buy more than one, we will give you a discount, if you receive the price, please contact us, we will try our best to make you satisfied, our customers come from all over the world, welcome to China.
